Load Cells – Compression

Category:

Description

Dynamic Rigging Hire have two compression load cell systems available for hire:

  • Single 10t Delphi compression load cell 105mm x 40mm low profile mounted to 12mm base plate, cabled (9m) to simple but effective LCD display unit with 5kg resolution. Issued with a current calibration certificate and packed in a pelican case for transit.
  • Single 25t Delphi compression load cell 125mm x 48mm low profile mounted to 18mm base plate, cabled (9m) to simple but effective LCD display unit with 10kg resolution. Issued with a current calibration certificate and packed in pelican case for transit.
  • 4 x 50 tonne units – resolution in 10kg and each load cell is class A from 5 tonne, 10m cable with military style plugs to a junction control box that displays individual load cell readings and sum total with an in built ticket printer.
  • 4 x 100 tonne units – Annular type load cell with full perimeter rim bolt down holes and an optional drop in dome cap to increase height, resolution is 20kg and class A from 5 tonne. Each load cell is cabled to a small LCD digital display unit.

Both systems are issued with current NATA calibration certification, detailed user notes and are shipped in secure entertainment industry type road cases.

DOWNLOAD 4 x 50t BROCHURE
DOWNLOAD 4 x 100t BROCHURE

Note: The information on this page is indicative only. Please consult our team before undertaking any operations with this device.
